ADF7010BRUZ-REEL7
IC XMITTER ASK/FSK/GFSK 24TSSOPManufacturer: Analog Devices Inc.
Categories: RF Transmitters
Quality Control: Learn More
Analog Devices Inc. ADF7010BRUZ-REEL7 is a versatile RF transmitter IC supporting ASK, FSK, and GFSK modulation. Operating within the 902MHz to 928MHz frequency band, this component delivers output power ranging from -16dBm to 12dBm. It supports a maximum data rate of 76.8kbps and features a PCB, surface mount antenna interface. The ADF7010BRUZ-REEL7 is housed in a 24-TSSOP package with a 0.173" (4.40mm) width, suitable for surface mounting. This device is designed for applications including data transfer, remote keyless entry (RKE), and remote control/security systems. It operates from a 2.3V to 3.6V supply voltage and has an operating temperature range of -40°C to 85°C.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | 24-TSSOP (0.173"", 4.40mm Width) |
| Mounting Type | Surface Mount |
| Frequency | 902MHz ~ 928MHz |
| Memory Size | - |
| Modulation or Protocol | ASK, FSK, GFSK |
| Data Interface | PCB, Surface Mount |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 2.3V ~ 3.6V |
| Power - Output | -16dBm ~ 12dBm |
| Applications | Data Transfer, RKE, Remote Control/Security Systems |
| Data Rate (Max) | 76.8kbps |
| Current - Transmitting | 40mA |
| Antenna Connector | PCB, Surface Mount |
| Supplier Device Package | 24-TSSOP |
| Programmable | Not Verified |
