ADRV9009BBCZ-REEL
RF TXRX MODULE CELL SMDManufacturer: Analog Devices Inc.
Categories: RF Transceiver Modules and Modems
Quality Control: Learn More
Analog Devices Inc. ADRV9009BBCZ-REEL is a highly integrated, wideband RF transceiver module designed for cellular applications. This surface mount component covers a broad frequency range from 75MHz to 6GHz, offering exceptional flexibility for diverse wireless system designs. Key features include a data rate of up to 12.3Gbps, facilitating high-throughput communication. It operates from a 1.3V to 1.8V supply and features serial interfaces such as JTAG and SPI for control and configuration. The module is supplied in a 196-LFBGA, CSPBGA package and is delivered on a tape and reel for automated assembly. Applications span base stations, advanced wireless infrastructure, and test and measurement equipment. The operating temperature range is -40°C to 85°C, ensuring reliable performance across demanding environmental conditions.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 10 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 196-LFBGA, CSPBGA |
| Sensitivity | - |
| Mounting Type | Surface Mount |
| Frequency | 75MHz ~ 6GHz |
| Memory Size | - |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 1.3V ~ 1.8V |
| Power - Output | 9dBm |
| Data Rate | 12.3Gbps |
| Protocol | - |
| Current - Receiving | - |
| Current - Transmitting | - |
| Antenna Type | - |
| Utilized IC / Part | - |
| Modulation | - |
| RF Family/Standard | Cellular |
| Serial Interfaces | JTAG, SPI |
| Programmable | Not Verified |
