HMC393MS8GE
IC RF SWITCH DPDT 6GHZ 8MSOPManufacturer: Analog Devices Inc.
Categories: RF Switches
Quality Control: Learn More
Analog Devices Inc. HMC393MS8GE is a DPDT RF switch designed for high-frequency applications. This component operates within a 5GHz to 6GHz frequency range, offering a typical insertion loss of 1.2dB and 20dB isolation at 6GHz. It features an IIP3 of 49dBm, making it suitable for demanding RF signal path control. The device is presented in a compact 8-MSOP surface-mount package, specified for a 5V supply voltage. Its reflective topology is well-suited for wireless infrastructure, radar systems, and test and measurement equipment requiring precise RF signal switching. The operating temperature range is -40°C to 85°C.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | 8-TSSOP, 8-MSOP (0.118"", 3.00mm Width) |
| Impedance | 50Ohm |
| Mounting Type | Surface Mount |
| Circuit | DPDT |
| RF Type | HiperLAN, UNII |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 5V |
| Insertion Loss | 1.2dB |
| Frequency Range | 5GHz ~ 6GHz |
| Topology | Reflective |
| P1dB | - |
| Test Frequency | 6GHz |
| Isolation | 20dB |
| Supplier Device Package | 8-MSOP |
| IIP3 | 49dBm |
