HMC344LP3
IC RF SWITCH SP4T 8GHZ 16QFNManufacturer: Analog Devices Inc.
Categories: RF Switches
Quality Control: Learn More
Analog Devices Inc. HMC344LP3 is a Single Pole Four Throw (SP4T) RF switch designed for high-frequency applications. Operating from DC up to 8 GHz, this absorptive switch offers 50 Ohm impedance and features insertion loss of 1.8 dB at 6 GHz. Isolation is rated at 40 dB, with an IIP3 of 40 dBm and a P1dB of 21 dBm. The HMC344LP3 is housed in a compact 16-QFN (3x3) package with an exposed pad, suitable for surface mounting. This component is ideal for use in wireless infrastructure, WLAN, and other RF systems requiring efficient signal routing. The operating temperature range is -40°C to 85°C.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: StripDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Strip |
| Package / Case | 16-VFQFN Exposed Pad |
| Impedance | 50Ohm |
| Mounting Type | Surface Mount |
| Circuit | SP4T |
| RF Type | WLAN |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | - |
| Insertion Loss | 1.8dB |
| Frequency Range | 0Hz ~ 8GHz |
| Topology | Absorptive |
| P1dB | 21dBm |
| Test Frequency | 6GHz |
| Isolation | 40dB |
| Supplier Device Package | 16-QFN (3x3) |
| IIP3 | 40dBm |
