HMC284MS8GE
IC RF SWITCH SPDT 3.5GHZ 8MSOPManufacturer: Analog Devices Inc.
Categories: RF Switches
Quality Control: Learn More
Analog Devices Inc. HMC284MS8GE is a general-purpose, absorptive SPDT RF switch operating from DC to 3.5 GHz. This component offers a typical insertion loss of 0.7 dB and excellent isolation of 33 dB at 3.5 GHz. It features a P1dB of 24 dBm and an IIP3 of 48 dBm, making it suitable for demanding RF applications. The HMC284MS8GE is presented in an 8-MSOP-EP package with an exposed pad, designed for surface mounting. Key applications include wireless infrastructure, radar systems, and test and measurement equipment. The impedance is specified at 50 Ohms, and it operates across a temperature range of -40°C to 85°C.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-TSSOP, 8-MSOP (0.118"", 3.00mm Width) Exposed Pad |
| Impedance | 50Ohm |
| Mounting Type | Surface Mount |
| Circuit | SPDT |
| RF Type | General Purpose |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | - |
| Insertion Loss | 0.7dB |
| Frequency Range | 0Hz ~ 3.5GHz |
| Topology | Absorptive |
| P1dB | 24dBm |
| Test Frequency | 3.5GHz |
| Isolation | 33dB |
| Supplier Device Package | 8-MSOP-EP |
| IIP3 | 48dBm |
