HMC316MS8E
IC MIXER HI-IP3 DBL-BAL 8-MSOPManufacturer: Analog Devices Inc.
Categories: RF Mixers
Quality Control: Learn More
Analog Devices Inc. HMC316MS8E is a high-intercept point, double-balanced RF mixer designed for general-purpose up and down conversion applications. This component operates across a frequency range of 1.5GHz to 3.8GHz and features a noise figure of 8dB. It is housed in an 8-MSOP package, suitable for surface mount integration. The HMC316MS8E is utilized in various demanding industries, including telecommunications infrastructure, satellite communications, and electronic warfare systems where precise RF signal manipulation is critical. Its design facilitates robust performance in complex RF signal chains.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: StripDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Strip |
| Package / Case | 8-TSSOP, 8-MSOP (0.118"", 3.00mm Width) |
| Mounting Type | Surface Mount |
| Frequency | 1.5GHz ~ 3.8GHz |
| RF Type | General Purpose |
| Voltage - Supply | - |
| Gain | - |
| Current - Supply | - |
| Secondary Attributes | Up/Down Converter |
| Noise Figure | 8dB |
| Number of Mixers | 1 |
| Supplier Device Package | 8-MSOP |
