ADL5812ACPZ-R7
IC MXR 700MHZ-2.8GHZ AMP 40LFCSPManufacturer: Analog Devices Inc.
Categories: RF Mixers
Quality Control: Learn More
Analog Devices Inc. presents the ADL5812ACPZ-R7, a high-performance dual-channel RF mixer. This general-purpose mixer operates across a broad frequency range of 700MHz to 2.8GHz, featuring an integrated amplifier for enhanced signal processing. The device is supplied in a compact 40-LFCSP-VQ (6x6) package, suitable for surface mount applications. With a typical supply voltage range of 3.6V to 5.5V and a current draw of 412mA, the ADL5812ACPZ-R7 offers a gain of 6.7dB and a noise figure of 11.6dB. Its robust design makes it suitable for demanding applications in wireless infrastructure, radar systems, and test and measurement equipment. The component is delivered in tape and reel packaging.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 40-VFQFN Exposed Pad, CSP |
| Mounting Type | Surface Mount |
| Frequency | 700MHz ~ 2.8GHz |
| RF Type | General Purpose |
| Voltage - Supply | 3.6V ~ 5.5V |
| Gain | 6.7dB |
| Current - Supply | 412mA |
| Secondary Attributes | With Amplifier |
| Noise Figure | 11.6dB |
| Number of Mixers | 2 |
| Supplier Device Package | 40-LFCSP-VQ (6x6) |
