ADL5354ACPZ-R7
IC MIXER 2.2-2.7GHZ 36LFCSPManufacturer: Analog Devices Inc.
Categories: RF Mixers
Quality Control: Learn More
Analog Devices Inc. ADL5354ACPZ-R7 is a high-performance, double-balanced RF mixer IC designed for cellular frequency bands. This component operates within the 2.2GHz to 2.7GHz range, offering a typical conversion gain of 14dB. Featuring two integrated mixers, the ADL5354ACPZ-R7 exhibits a noise figure of 9.9dB and supports supply voltages from 3.3V to 5V, drawing a current of 350mA. The device is supplied in a 36-LFCSP-VQ (6x5.75) package, utilizing surface mount technology. This RF mixer finds application in wireless infrastructure and communication systems requiring efficient frequency downconversion. The component is delivered on a tape and reel for automated assembly.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 36-VFQFN Exposed Pad, CSP |
| Mounting Type | Surface Mount |
| Frequency | 2.2GHz ~ 2.7GHz |
| RF Type | Cellular |
| Voltage - Supply | 3.3V ~ 5V |
| Gain | 14dB |
| Current - Supply | 350mA |
| Secondary Attributes | - |
| Noise Figure | 9.9dB |
| Number of Mixers | 2 |
| Supplier Device Package | 36-LFCSP-VQ (6x5.75) |
