AD8343ARU-REEL
IC MIXER ACTIVE HI-IP3 14-TSSOPManufacturer: Analog Devices Inc.
Categories: RF Mixers
Quality Control: Learn More
Analog Devices Inc. AD8343ARU-REEL is a single-balanced, active RF mixer designed for up/down conversion applications. This component operates across a broad frequency range from 0Hz to 2.5GHz, making it suitable for cellular and WLAN systems. The AD8343 mixer offers a typical gain of 7dB and a high input third-order intercept point (IP3) for excellent linearity. Its low noise figure of 14dB contributes to superior signal integrity. Packaged in a 14-TSSOP (0.173", 4.40mm Width) surface-mount configuration, it requires a supply voltage between 4.5V and 5.5V, with a typical current draw of 60mA. This device is commonly utilized in radio frequency front-end architectures.
Additional Information
Series: AD8343RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 14-TSSOP (0.173"", 4.40mm Width) |
| Mounting Type | Surface Mount |
| Frequency | 0Hz ~ 2.5GHz |
| RF Type | Cellular, WLAN |
| Voltage - Supply | 4.5V ~ 5.5V |
| Gain | 7dB |
| Current - Supply | 60mA |
| Secondary Attributes | Up/Down Converter |
| Noise Figure | 14dB |
| Number of Mixers | 1 |
| Supplier Device Package | 14-TSSOP |
