AD9857AST
IC QUADRATURE DGTL UPCONV 80LQFPManufacturer: Analog Devices Inc.
Categories: RF Misc ICs and Modules
Quality Control: Learn More
Analog Devices Inc. AD9857AST is a high-performance quadrature digital upconverter IC from the AD9857 series. Designed for demanding RF applications, this component facilitates signal conversion within a frequency range of 5MHz to 200MHz. It is engineered for operation in HFC cable network infrastructure, providing efficient upconversion capabilities. The device features a robust 80-LQFP package, measuring 14x14mm, suitable for surface-mount assembly. Its architecture is optimized for applications requiring precise signal modulation and frequency translation, making it a critical element in advanced communication systems.
Additional Information
Series: AD9857RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BagDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bag |
| Package / Case | 80-LQFP |
| Mounting Type | Surface Mount |
| Function | Upconverter |
| Frequency | 5MHz ~ 200MHz |
| RF Type | HFC Cable Network |
| Secondary Attributes | - |
| Supplier Device Package | 80-LQFP (14x14) |
