AD9856AST
IC QUADRATURE DGTL UPCONV 48TQFPManufacturer: Analog Devices Inc.
Categories: RF Misc ICs and Modules
Quality Control: Learn More
Analog Devices Inc. AD9856AST is a Quadrature Digital Upconverter, part of the AD9856 series. This 48-TQFP (7x7) packaged component functions as an RF Upconverter, specifically designed for HFC Cable Network applications. Operating within a frequency range of 5MHz to 200MHz, the AD9856AST facilitates the conversion of baseband digital signals to intermediate frequencies suitable for transmission. Its surface mount technology ensures efficient integration into complex circuit designs. This device is commonly utilized in broadband access, cable television distribution, and other high-frequency communication systems where precise signal modulation and upconversion are critical.
Additional Information
Series: AD9856RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BagDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bag |
| Package / Case | 48-LQFP |
| Mounting Type | Surface Mount |
| Function | Upconverter |
| Frequency | 5MHz ~ 200MHz |
| RF Type | HFC Cable Network |
| Secondary Attributes | - |
| Supplier Device Package | 48-LQFP (7x7) |
