AD8347ARU
RF DEMOD IC 800MZ-2.7GHZ 28TSSOPManufacturer: Analog Devices Inc.
Categories: RF Demodulators
Quality Control: Learn More
Analog Devices Inc. AD8347ARU is a versatile RF demodulator IC operating across an 800 MHz to 2.7 GHz frequency range. This surface mount component, housed in a 28-TSSOP package, offers a gain of 39.5 dB and a noise figure of 11 dB. Its P1dB compression point is -30 dBm, supporting efficient signal processing. The device requires a supply voltage between 2.7V and 5.5V, drawing a nominal current of 80 mA. The AD8347ARU is suitable for applications in wireless communication systems, including cellular infrastructure and broadband wireless access.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 28-TSSOP (0.173"", 4.40mm Width) |
| Mounting Type | Surface Mount |
| Function | Demodulator |
| Voltage - Supply | 2.7V ~ 5.5V |
| Gain | 39.5dB |
| Noise Figure | 11dB |
| P1dB | -30dBm |
| LO Frequency | 800MHz ~ 2.7GHz |
| RF Frequency | 800MHz ~ 2.7GHz |
| Supplier Device Package | 28-TSSOP |
| Current - Supply | 80 mA |
