HMC564LC4
IC RF AMP GPS 6GHZ-14GHZ 24QFNManufacturer: Analog Devices Inc.
Categories: RF Amplifiers
Quality Control: Learn More
The Analog Devices Inc. HMC564LC4 is a versatile RF amplifier IC designed for general-purpose applications within the 6GHz to 14GHz frequency range. This component features a typical gain of 17dB and a noise figure of 1.8dB, making it suitable for demanding RF signal chain designs. The device operates with a supply voltage of 2.5V to 3.5V and draws a current of 75mA. With a P1dB output power of 13dBm, it offers robust signal amplification. The HMC564LC4 is housed in a compact 24-QFN (4x4) exposed pad package, facilitating surface mount assembly. This amplifier is commonly utilized in applications such as point-to-point radio, satellite communications, and electronic warfare systems where high-performance RF amplification is critical.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 13 week(s)Product Status: ActivePackaging: StripDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Strip |
| Package / Case | 24-TFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Frequency | 6GHz ~ 14GHz |
| RF Type | General Purpose |
| Voltage - Supply | 2.5V ~ 3.5V |
| Gain | 17dB |
| Current - Supply | 75mA |
| Noise Figure | 1.8dB |
| P1dB | 13dBm |
| Test Frequency | - |
| Supplier Device Package | 24-QFN (4x4) |
| Grade | - |
| Qualification | - |
