HMC-C024
IC RF AMP VSAT 10MHZ-20GHZ MODManufacturer: Analog Devices Inc.
Categories: RF Amplifiers
Quality Control: Learn More
Analog Devices Inc. HMC-C024 is a high-performance RF amplifier module designed for demanding VSAT applications. This component operates across a broad frequency range from 10 MHz to 20 GHz, providing a typical gain of 16 dB. The HMC-C024 exhibits a noise figure of 3.5 dB and a P1dB output power of 24 dBm at the specified test frequency. It is designed for connector mount installations, featuring SMA connectors, and is supplied in a module package. The device requires a supply voltage between 11 V and 16 V, drawing a current of 225 mA. This RF amplifier finds utility in satellite communications and other advanced wireless infrastructure.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 39 week(s)Product Status: ActivePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Box |
| Package / Case | Module, SMA Connectors |
| Mounting Type | Connector Mount |
| Frequency | 10MHz ~ 20GHz |
| RF Type | VSAT |
| Voltage - Supply | 11V ~ 16V |
| Gain | 16dB |
| Current - Supply | 225mA |
| Noise Figure | 3.5dB |
| P1dB | 24dBm |
| Test Frequency | - |
| Supplier Device Package | Module |
Request a Quote
