ADL5240ACPZ-R7
IC RF AMP 100MHZ-4GHZ 32LFCSPManufacturer: Analog Devices Inc.
Categories: RF Amplifiers
Quality Control: Learn More
Analog Devices Inc. ADL5240ACPZ-R7 is a high-performance RF amplifier IC covering a wide frequency range from 100MHz to 4GHz. This component offers a typical gain of 19.6dB at 3.6GHz, with a noise figure of 3.1dB, making it suitable for demanding RF signal chain applications. The device is designed for surface mount installation within a 32-LFCSP-VQ (5x5) package, supplied on tape and reel. Operating from a supply voltage of 4.75V to 5.25V, it draws a quiescent current of 93mA. Key performance metrics include a P1dB output power of 18.8dB. This amplifier finds application in areas such as wireless infrastructure, test and measurement equipment, and radar systems.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 32-VFQFN Exposed Pad, CSP |
| Mounting Type | Surface Mount |
| Frequency | 100MHz ~ 4GHz |
| RF Type | - |
| Voltage - Supply | 4.75V ~ 5.25V |
| Gain | 19.6dB |
| Current - Supply | 93mA |
| Noise Figure | 3.1dB |
| P1dB | 18.8dB |
| Test Frequency | 3.6GHz |
| Supplier Device Package | 32-LFCSP-VQ (5x5) |
