AD8353ACP-REEL7
IC RF GAIN BLOCK 8-LFCSP T/RManufacturer: Analog Devices Inc.
Categories: RF Amplifiers
Quality Control: Learn More
Analog Devices Inc. AD8353ACP-REEL7 is a broadband, high-linearity RF gain block IC. Operating from 1MHz to 2.7GHz, this component is engineered for demanding wireless applications including cellular infrastructure, Local Multipoint Distribution Service (LMDS), and Multipoint Microwave Distribution Service (MMDS). It delivers a typical gain of 15.6dB at 2.7GHz, with a noise figure of 6.8dB and a P1dB compression point of 6.3dBm at the same test frequency. The device supports dual supply voltages of 3V and 5V, drawing a quiescent current between 35mA and 48mA. The AD8353ACP-REEL7 is provided in an 8-LFCSP-VD (3x2) package, suitable for surface-mount assembly.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 8-VFDFN Exposed Pad, CSP |
| Mounting Type | Surface Mount |
| Frequency | 1MHz ~ 2.7GHz |
| RF Type | Cellular, LMDS, MMDS |
| Voltage - Supply | 3V, 5V |
| Gain | 15.6dB |
| Current - Supply | 35mA ~ 48mA |
| Noise Figure | 6.8dB |
| P1dB | 6.3dBm |
| Test Frequency | 2.7GHz |
| Supplier Device Package | 8-LFCSP-VD (3x2) |
