ADM869LARQ
IC SW HIGH-SIDE P-CH 16QSOPManufacturer: Analog Devices Inc.
Categories: Power Distribution Switches, Load Drivers
Quality Control: Learn More
Analog Devices Inc. ADM869LARQ is a six-channel high-side power distribution switch designed for demanding applications. This 16-QSOP packaged component delivers up to 2A per channel with a typical Rds (On) of 45mOhm, facilitating efficient power management. Operating across a voltage range of 2.7V to 5.5V, the ADM869LARQ features non-inverting input control for its high-side output configuration. Its robust design is suitable for use in industrial automation, telecommunications, and computing systems where reliable power control is critical. The surface-mount device is supplied in a tube package, ensuring ease of integration into automated assembly processes.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 16-SSOP (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Number of Outputs | 6 |
| Operating Temperature | -40°C ~ 85°C |
| Output Configuration | High Side |
| Rds On (Typ) | 45mOhm |
| Input Type | Non-Inverting |
| Voltage - Load | 2.7V ~ 5.5V |
| Current - Output (Max) | 2A |
| Supplier Device Package | 16-QSOP |
