LT1121CZ-3.3#TRPBF
IC REG LINEAR 3.3V 150MA TO92-3Manufacturer: Analog Devices Inc.
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
Linear Voltage Regulator IC Positive Fixed 1 Output 150mA TO-92-3
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 10 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) Formed Leads |
| Output Type | Fixed |
| Mounting Type | Through Hole |
| Current - Output | 150mA |
| Operating Temperature | 0°C ~ 125°C |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 50 µA |
| Voltage - Input (Max) | 30V |
| Number of Regulators | 1 |
| Supplier Device Package | TO-92-3 |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 3.3V |
| Control Features | Enable |
| PSRR | 58dB (120Hz) |
| Voltage Dropout (Max) | 0.7V @ 150mA |
| Protection Features | Over Temperature, Reverse Polarity |
| Current - Supply (Max) | 14 mA |
