ADP1765ACPZ-1.5-R7
IC REG LDOManufacturer: Analog Devices Inc.
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
Analog Devices Inc. ADP1765ACPZ-1-5-R7 is a high-performance, positive fixed output linear voltage regulator designed for demanding applications. This component delivers a stable 1.5V output with a maximum output current of 5A, making it suitable for powering sensitive analog and mixed-signal circuitry. Key features include integrated Enable, Power Good, and Soft Start functions for controlled power sequencing. Protection mechanisms such as current limit and thermal overload are incorporated to ensure robust operation. The device boasts a Power Supply Rejection Ratio (PSRR) ranging from 61dB to 33dB across the 10kHz to 1MHz frequency spectrum. Packaged in a compact 16-LFCSP (3x3) with an exposed pad for enhanced thermal dissipation, the ADP1765ACPZ-1-5-R7 operates across an industrial temperature range of -40°C to 125°C. This regulator finds application in sectors such as industrial automation, telecommunications, and high-reliability computing systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Cut Tape (CT)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Cut Tape (CT) |
| Package / Case | 16-WFQFN Exposed Pad, CSP |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Current - Output | 5A |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 17 mA |
| Voltage - Input (Max) | 1.98V |
| Number of Regulators | 1 |
| Supplier Device Package | 16-LFCSP (3x3) |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 1.5V |
| Control Features | Enable, Power Good, Soft Start |
| PSRR | 61dB ~ 33dB (10kHz ~ 1MHz) |
| Voltage Dropout (Max) | - |
| Protection Features | Current Limit, Thermal Overload |
| Current - Supply (Max) | 25 mA |
