ADA4861-3YRZ-RL
IC OPAMP CFA 3 CIRCUIT 14SOICManufacturer: Analog Devices Inc.
Categories: Instrumentation, Op Amps, Buffer Amps
Quality Control: Learn More
Analog Devices Inc. ADA4861-3YRZ-RL is a triple-channel current feedback operational amplifier. This high-speed amplifier offers a -3dB bandwidth of 370 MHz and a slew rate of 680 V/µs, making it suitable for demanding applications. With an input bias current of 2.9 µA and an output current capability of 100 mA per channel, it provides robust performance. The ADA4861-3YRZ-RL operates from a supply voltage range of 5 V to 12 V, consuming 17.9 mA per channel.
Featuring a low input offset voltage of 100 µV, this device is designed for precision signal amplification. The 14-SOIC package facilitates surface mounting, and the component is supplied on a tape and reel for automated assembly. The ADA4861-3YRZ-RL is utilized in industries such as test and measurement, medical imaging, and high-speed data acquisition systems. It operates within a temperature range of -40°C to 105°C.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 14-SOIC (0.154"", 3.90mm Width) |
| Output Type | - |
| Mounting Type | Surface Mount |
| Amplifier Type | Current Feedback |
| Operating Temperature | -40°C ~ 105°C |
| Current - Supply | 17.9mA |
| Slew Rate | 680V/µs |
| Current - Input Bias | 2.9 µA |
| Voltage - Input Offset | 100 µV |
| Supplier Device Package | 14-SOIC |
| Number of Circuits | 3 |
| Current - Output / Channel | 100 mA |
| -3db Bandwidth | 370 MHz |
| Voltage - Supply Span (Min) | 5 V |
| Voltage - Supply Span (Max) | 12 V |
