ADA4841-2YCPZ-R2
IC OPAMP GP 2 CIRCUIT 8LFCSPManufacturer: Analog Devices Inc.
Categories: Instrumentation, Op Amps, Buffer Amps
Quality Control: Learn More
Analog Devices Inc. ADA4841-2YCPZ-R2 is a high-performance, dual-channel, general-purpose operational amplifier. This device features a wide bandwidth of 80 MHz and a slew rate of 13 V/µs, making it suitable for demanding signal processing applications. The rail-to-rail output stage maximizes dynamic range, while the low input bias current of 3 µA minimizes errors in high-impedance circuits. Operating from a 2.7 V to 12 V supply span, the ADA4841-2YCPZ-R2 consumes only 1.2 mA per channel. Its low input offset voltage of 40 µV and an output current capability of 60 mA per channel further enhance its utility. The 8-LFCSP-WD (3x3) package with an exposed pad ensures efficient thermal management and is supplied on tape and reel. This component is commonly found in instrumentation, medical devices, and high-speed data acquisition systems.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-WFDFN Exposed Pad, CSP |
| Output Type | Rail-to-Rail |
| Mounting Type | Surface Mount |
| Amplifier Type | General Purpose |
| Operating Temperature | -40°C ~ 125°C |
| Current - Supply | 1.2mA (x2 Channels) |
| Slew Rate | 13V/µs |
| Current - Input Bias | 3 µA |
| Voltage - Input Offset | 40 µV |
| Supplier Device Package | 8-LFCSP-WD (3x3) |
| Number of Circuits | 2 |
| Current - Output / Channel | 60 mA |
| -3db Bandwidth | 80 MHz |
| Voltage - Supply Span (Min) | 2.7 V |
| Voltage - Supply Span (Max) | 12 V |
