AD8139ARD
IC OPAMP DIFF 1 CIRCUIT 8SOICManufacturer: Analog Devices Inc.
Categories: Instrumentation, Op Amps, Buffer Amps
Quality Control: Learn More
Analog Devices Inc. AD8139ARD is a single-circuit, high-speed differential amplifier. This component features a 410 MHz -3dB bandwidth and a 800 V/µs slew rate, making it suitable for demanding signal processing applications. The rail-to-rail output capability, coupled with a 100 mA output current, ensures robust performance across various signal levels. Operating from a 4.5 V to 12 V supply span, the AD8139ARD exhibits a low input bias current of 2.25 µA and an input offset voltage of 150 µV. This device is housed in an 8-SOIC-EP package with an exposed pad for enhanced thermal management, suitable for surface mounting. Its specifications lend themselves to use in test and measurement equipment, video processing, and communication systems.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) Exposed Pad |
| Output Type | Differential, Rail-to-Rail |
| Mounting Type | Surface Mount |
| Amplifier Type | Differential |
| Operating Temperature | -40°C ~ 125°C |
| Current - Supply | 24.5mA |
| Slew Rate | 800V/µs |
| Current - Input Bias | 2.25 µA |
| Voltage - Input Offset | 150 µV |
| Supplier Device Package | 8-SOIC-EP |
| Number of Circuits | 1 |
| Current - Output / Channel | 100 mA |
| -3db Bandwidth | 410 MHz |
| Voltage - Supply Span (Min) | 4.5 V |
| Voltage - Supply Span (Max) | 12 V |
