AD203SN
IC OPAMP ISOLATION 1 CIRC 11DIPManufacturer: Analog Devices Inc.
Categories: Instrumentation, Op Amps, Buffer Amps
Quality Control: Learn More
Analog Devices Inc. AD203SN is a monolithic isolation amplifier featuring a single operational amplifier channel. This component is designed for robust performance in demanding environments, evident in its wide operating temperature range of -55°C to 125°C. With a low input bias current of 30 pA and a minimal input offset voltage of 5 mV, it is suitable for precision signal acquisition. The device operates with a supply voltage span from 12 V to 15 V, drawing a supply current of 20 mA. Its 10 kHz gain bandwidth product and 0.5 V/µs slew rate support accurate amplification of slowly varying signals. The AD203SN is housed in an 11-lead PDIP package, facilitating through-hole mounting. This isolation amplifier finds application in industrial control, medical instrumentation, and measurement systems where signal integrity and ground loop elimination are critical.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 38-DIP (0.500"", 12.70mm), 11 Leads |
| Output Type | - |
| Mounting Type | Through Hole |
| Amplifier Type | Isolation |
| Operating Temperature | -55°C ~ 125°C |
| Current - Supply | 20mA |
| Slew Rate | 0.5V/µs |
| Gain Bandwidth Product | 10 kHz |
| Current - Input Bias | 30 pA |
| Voltage - Input Offset | 5 mV |
| Supplier Device Package | 11-PDIP |
| Number of Circuits | 1 |
| Current - Output / Channel | 4 mA |
| Voltage - Supply Span (Min) | 12 V |
| Voltage - Supply Span (Max) | 15 V |
