AD202JY
IC OPAMP ISOLATION 2 CIRC 11SIPManufacturer: Analog Devices Inc.
Categories: Instrumentation, Op Amps, Buffer Amps
Quality Control: Learn More
Analog Devices Inc. AD202JY is a 2-circuit isolation amplifier housed in an 11-lead SIP package. Featuring a low input bias current of 30 pA and an output current of 400 µA per channel, this component is designed for robust signal isolation applications. The gain bandwidth product is rated at 2 kHz. Operating across a temperature range of -40°C to 85°C, the AD202JY supports a supply voltage span from 13.5 V to 16.5 V with a typical supply current of 5 mA. The through-hole mounting type and the 11-SIP supplier device package facilitate integration into various electronic designs. This isolation amplifier is commonly utilized in industrial automation, medical instrumentation, and power system monitoring.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 38-SIP, 11 Leads, Offset Leads |
| Output Type | - |
| Mounting Type | Through Hole |
| Amplifier Type | Isolation |
| Operating Temperature | -40°C ~ 85°C |
| Current - Supply | 5mA |
| Slew Rate | - |
| Gain Bandwidth Product | 2 kHz |
| Current - Input Bias | 30 pA |
| Voltage - Input Offset | 15 mV |
| Supplier Device Package | 11-SIP |
| Number of Circuits | 2 |
| Current - Output / Channel | 400 µA |
| Voltage - Supply Span (Min) | 13.5 V |
| Voltage - Supply Span (Max) | 16.5 V |
