ADXRS620BBGZ
IC GYROSCOPE YAW RATE 32-CBGAManufacturer: Analog Devices Inc.
Categories: Gyroscopes
Quality Control: Learn More
Analog Devices Inc. ADXRS620BBGZ is a high-performance Z-axis (Yaw) rate sensor with a measurement range of ±300 °/s. This component features a robust 32-BFCBGA package and offers an analog voltage output with a sensitivity of 6 mV/°/s. The bandwidth is adjustable from 0.01 Hz to 2.5 kHz, providing flexibility for various application requirements. Operating across a temperature range of -40°C to 105°C, the ADXRS620BBGZ also includes an integrated temperature sensor for compensation. It is designed for demanding applications in aerospace, defense, and industrial automation. The device operates from a supply voltage of 4.75V to 5.25V and draws a typical supply current of 3.5 mA.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 33 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Adjustable Bandwidth, Temperature Sensor |
| Packaging | Bulk |
| Package / Case | 32-BFCBGA |
| Output Type | Analog Voltage |
| Type | Analog |
| Axis | Z (Yaw) |
| Operating Temperature | -40°C ~ 105°C |
| Voltage - Supply | 4.75V ~ 5.25V |
| Bandwidth | 0.01Hz ~ 2.5kHz |
| Range °/s | ±300 |
| Sensitivity (mV/°/s) | 6 |
| Sensitivity (LSB/(°/s)) | - |
| Current - Supply | 3.5 mA |
