LTC3900ES8#PBF
IC GATE DRVR LOW-SIDE 8SOICManufacturer: Analog Devices Inc.
Categories: Gate Drivers
Quality Control: Learn More
Analog Devices Inc. LTC3900ES8-PBF is a dual, low-side gate driver designed for N-channel MOSFETs. This inverting and non-inverting driver features synchronized operation and delivers 2A peak output current in both source and sink configurations. With a supply voltage range of 4.5V to 11V, the LTC3900ES8-PBF offers typical rise and fall times of 15ns. The 8-SOIC package is suitable for surface mount applications, commonly found in power supply control, motor drive, and DC-DC converter designs. Operating across a temperature range of -40°C to 125°C (TJ), this component provides robust performance for demanding applications.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 10 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Voltage - Supply | 4.5V ~ 11V |
| Input Type | Inverting, Non-Inverting |
| Supplier Device Package | 8-SO |
| Rise / Fall Time (Typ) | 15ns, 15ns |
| Channel Type | Synchronous |
| Driven Configuration | Low-Side |
| Number of Drivers | 2 |
| Gate Type | N-Channel MOSFET |
| Logic Voltage - VIL, VIH | - |
| Current - Peak Output (Source, Sink) | 2A, 2A |
| Programmable | Not Verified |
