DS28E05X+T
EEPROM, 112X8, Serial, CMOS, PBGA4Manufacturer: Analog Devices Inc.
Categories: EEPROMs
Quality Control: Learn More
Analog Devices Inc. DS28E05X-T is a serial CMOS EEPROM with an 112x8 memory organization. This component features a 1-Wire serial bus interface, operating asynchronously from 1.71V to 3.63V. The DS28E05 series device is housed in a 4-ball very thin profile, fine pitch ball grid array (VFBGA) package, designated S-PBGA-B4, with a terminal pitch of 0.400mm. It offers a memory density of 896 bits and operates across a temperature range of -40°C to +85°C. This device is suitable for applications requiring secure identification, authentication, and data storage within industrial, consumer, and medical electronics.
Additional Information
Series: DS28E05RoHS Status: RoHS CompliantManufacturer Lead Time: Product Status: ActivePackaging: Datasheet:Download Free CAD Model:
Technical Details:
| Length | 0.9080 |
| Width | 0.9080 |
| Technology | CMOS |
| JESD_30_Code | S-PBGA-B4 |
| Memory_Density | 896.0000000000000000 |
| Memory_IC_Type | EEPROM |
| Memory_Organization | 112X8 |
| Memory_Width | 8 |
| Number_of_Functions | 1 |
| Number_of_Terminals | 4 |
| Number_of_Words | 112.0000000000000000 |
| Number_of_Words_Code | 112 |
| Operating_Mode | Asynchronous |
| Operating_Temperature_Max | 85.0 |
| Operating_Temperature_Min | -40.0 |
| Package_Body_Material | PLASTIC/EPOXY |
| Package_Code | VFBGA |
| Package_Shape | Square |
| Package_Style | GRID ARRAY, VERY THIN PROFILE, FINE PITCH |
| Parallel_Serial | Serial |
| Seated_Height_Max | 0.3700 |
| Serial_Bus_Type | 1-Wire |
| Supply_Voltage_Max | 3.63000 |
| Supply_Voltage_Min | 1.71000 |
| Surface_Mount | Yes |
| Terminal_Form | Ball |
| Terminal_Pitch | 0.400 |
| Terminal_Position | Bottom |
