AD8396ACPZ-RL
IC DRIVER 2/0 16LFCSPManufacturer: Analog Devices Inc.
Categories: Drivers, Receivers, Transceivers
Quality Control: Learn More
Analog Devices Inc. AD8396ACPZ-RL is a high-performance dual-channel voltage-feedback operational amplifier. This component is engineered for demanding applications requiring superior linearity and output drive capability. Featuring a wide supply voltage range from 6V to 24V and an operating temperature range of -40°C to 85°C, the AD8396ACPZ-RL is suitable for industrial, medical, and communications equipment. Its 16-LFCSP (4x4) package with an exposed pad ensures efficient thermal management for sustained high-power operation. The device is optimized for driving loads such as ADCs, video amplifiers, and cable drivers where signal integrity and robust performance are critical. The AD8396ACPZ-RL offers exceptional slew rate and bandwidth, making it an ideal choice for high-speed signal conditioning and amplification circuits.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 16-WQFN Exposed Pad, CSP |
| Mounting Type | Surface Mount |
| Type | Driver |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 6V ~ 24V |
| Number of Drivers/Receivers | 2/0 |
| Data Rate | - |
| Protocol | - |
| Supplier Device Package | 16-LFCSP (4x4) |
| Duplex | - |
Request a Quote
