AD8396ACPZ-R2
IC LINE DRVR ADSL/ADSL2 16LFCSPManufacturer: Analog Devices Inc.
Categories: Drivers, Receivers, Transceivers
Quality Control: Learn More
Analog Devices Inc. AD8396ACPZ-R2 is a dual, high-performance voltage-feedback operational amplifier. Designed for demanding applications, this transceiver features a rail-to-rail output stage and operates over a wide supply voltage range of 6V to 24V. The AD8396ACPZ-R2 is housed in a compact 16-lead LFCSP (4x4) package with an exposed pad for enhanced thermal performance. Its robust design and low distortion characteristics make it suitable for ADSL/ADSL2 line drivers, as well as signal amplification in telecommunications infrastructure and high-speed data transmission systems. This component offers a 2/0 driver/receiver configuration, ideal for applications requiring precise signal conditioning and robust drive capability.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 16-WQFN Exposed Pad, CSP |
| Mounting Type | Surface Mount |
| Type | Transceiver |
| Voltage - Supply | 6V ~ 24V |
| Number of Drivers/Receivers | 2/0 |
| Protocol | - |
| Supplier Device Package | 16-LFCSP (4x4) |
Request a Quote
