LTC2601IDD-1#PBF
IC DAC 16BIT V-OUT 10DFNManufacturer: Analog Devices Inc.
Categories: Digital to Analog Converters (DAC)
Quality Control: Learn More
The Analog Devices Inc. LTC2601IDD-1-PBF is a 16-bit, single-channel voltage-output digital-to-analog converter. This component features an SPI data interface for straightforward integration into complex systems. It offers a guaranteed monotonic performance with integral nonlinearity (INL) and differential nonlinearity (DNL) figures of ±13 LSB and ±1 LSB maximum, respectively. The device operates from a 2.5V to 5.5V analog and digital supply range, with a buffered voltage output. Its 10-DFN (3x3) package with an exposed pad is designed for surface mounting. The LTC2601IDD-1-PBF exhibits a typical settling time of 10µs. This DAC is suitable for applications in industrial automation, data acquisition, and precision instrumentation.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 10 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 10-WFDFN Exposed Pad |
| Output Type | Voltage - Buffered |
| Mounting Type | Surface Mount |
| Number of Bits | 16 |
| Data Interface | SPI |
| Reference Type | External |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply, Analog | 2.5V ~ 5.5V |
| Voltage - Supply, Digital | 2.5V ~ 5.5V |
| Settling Time | 10µs (Typ) |
| Supplier Device Package | 10-DFN (3x3) |
| Architecture | - |
| Number of D/A Converters | 1 |
| INL/DNL (LSB) | ±13, ±1 (Max) |
| Differential Output | No |
| Programmable | Not Verified |
