LTC1599ACN#PBF
IC DAC 16BIT A-OUT 24DIPManufacturer: Analog Devices Inc.
Categories: Digital to Analog Converters (DAC)
Quality Control: Learn More
Analog Devices Inc. LTC1599ACN-PBF is a 16-bit, single-channel digital-to-analog converter (DAC) featuring an R-2R architecture. This through-hole component is housed in a 24-PDIP package with a 0.300" width, designed for robust applications. The LTC1599ACN-PBF offers a true differential output and accepts a parallel data interface, ideal for systems requiring precise analog signal generation. Key performance specifications include a typical settling time of 1µs and excellent linearity with INL/DNL figures of ±0.35 LSB and ±0.2 LSB, respectively. It operates with analog and digital supply voltages of 5V and requires an external reference. The unbuffered current output provides flexibility for various output amplification stages. This DAC is suitable for use in industrial control systems, data acquisition, and high-fidelity audio processing.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 13 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 24-DIP (0.300"", 7.62mm) |
| Output Type | Current - Unbuffered |
| Mounting Type | Through Hole |
| Number of Bits | 16 |
| Data Interface | Parallel |
| Reference Type | External |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply, Analog | 5V |
| Voltage - Supply, Digital | 5V |
| Settling Time | 1µs (Typ) |
| Supplier Device Package | 24-PDIP |
| Architecture | R-2R |
| Number of D/A Converters | 1 |
| INL/DNL (LSB) | ±0.35, ±0.2 |
| Differential Output | Yes |
| Programmable | Not Verified |
