DAC8800FP
IC DAC 8BIT V-OUT 20DIPManufacturer: Analog Devices Inc.
Categories: Digital to Analog Converters (DAC)
Quality Control: Learn More
Analog Devices Inc. TrimDAC® series 8-bit, 8-channel voltage-output digital-to-analog converter, part number DAC8800FP. This component features a string DAC architecture with an SPI data interface for efficient communication. It offers a fast 2µs settling time and a ±1 LSB maximum INL/DNL specification. The DAC8800FP supports a wide analog supply voltage range of 4V to 16V, and -12V, with an unbuffered voltage output. Designed for through-hole mounting in a 20-PDIP package, it operates within an industrial temperature range of -40°C to 85°C. This device is commonly utilized in industrial automation, test and measurement equipment, and general-purpose data acquisition systems.
Additional Information
Series: TrimDAC®RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 20-DIP (0.300"", 7.62mm) |
| Output Type | Voltage - Unbuffered |
| Mounting Type | Through Hole |
| Number of Bits | 8 |
| Data Interface | SPI |
| Reference Type | External |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply, Analog | 4V ~ 16V, -12V |
| Voltage - Supply, Digital | - |
| Settling Time | 2µs |
| Supplier Device Package | 20-PDIP |
| Architecture | String DAC |
| Number of D/A Converters | 8 |
| INL/DNL (LSB) | -, ±1 (Max) |
| Differential Output | No |
| Programmable | Not Verified |
