AD9762ARZ
IC DAC 12BIT A-OUT 28SOICManufacturer: Analog Devices Inc.
Categories: Digital to Analog Converters (DAC)
Quality Control: Learn More
12 Bit Digital to Analog Converter 1 28-SOIC
Additional Information
Series: TxDAC®RoHS Status: ROHS3 CompliantManufacturer Lead Time: 10 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 28-SOIC (0.295"", 7.50mm Width) |
| Output Type | Current - Unbuffered |
| Mounting Type | Surface Mount |
| Number of Bits | 12 |
| Data Interface | Parallel |
| Reference Type | External, Internal |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply, Analog | 2.7V ~ 5.5V |
| Voltage - Supply, Digital | 2.7V ~ 5.5V |
| Settling Time | 35ns (Typ) |
| Supplier Device Package | 28-SOIC |
| Architecture | Current Source |
| Number of D/A Converters | 1 |
| INL/DNL (LSB) | ±1, ±0.75 |
| Differential Output | Yes |
| Programmable | Not Verified |
