AD9136BCPAZRL
IC DAC 16BIT A-OUT 88LFCSPManufacturer: Analog Devices Inc.
Categories: Digital to Analog Converters (DAC)
Quality Control: Learn More
Analog Devices Inc. TxDAC+® AD9136BCPAZRL is a dual 16-bit digital-to-analog converter featuring a current source architecture. This device supports the JESD204B data interface and offers a differential output. Key performance specifications include integral nonlinearity (INL) and differential nonlinearity (DNL) of ±2 LSB and ±1 LSB, respectively, with a typical settling time of 20ns. The AD9136BCPAZRL operates with analog supply voltages between 3.13V and 3.47V, and digital supply voltages between 1.14V and 1.26V. It utilizes an internal voltage reference and provides current unbuffered output. The component is housed in an 88-LFCSP-VQ (12x11.75) package, suitable for surface mounting. This converter is utilized in applications such as wireless communications, test and measurement equipment, and high-speed waveform generation.
Additional Information
Series: TxDAC+®RoHS Status: ROHS3 CompliantManufacturer Lead Time: 10 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 88-VFQFN Exposed Pad, CSP |
| Output Type | Current - Unbuffered |
| Mounting Type | Surface Mount |
| Number of Bits | 16 |
| Data Interface | JESD204B |
| Reference Type | Internal |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply, Analog | 3.13V ~ 3.47V |
| Voltage - Supply, Digital | 1.14V ~ 1.26V |
| Settling Time | 20ns (Typ) |
| Supplier Device Package | 88-LFCSP-VQ (12x11.75) |
| Architecture | Current Source |
| Number of D/A Converters | 2 |
| INL/DNL (LSB) | ±2, ±1 |
| Differential Output | Yes |
| Programmable | Not Verified |
