AD9125BCPZRL
IC DAC 16BIT A-OUT 72LFCSPManufacturer: Analog Devices Inc.
Categories: Digital to Analog Converters (DAC)
Quality Control: Learn More
Analog Devices Inc. AD9125BCPZRL is a dual 16-bit TxDAC+® digital-to-analog converter, featuring a current-source architecture with a parallel data interface. This component offers a differential output with typical INL and DNL specifications of ±3.7 LSB and ±2.1 LSB, respectively. The device supports external or internal voltage references and boasts a fast settling time of 20ns (typ). Packaged in a 72-LFCSP-VQ (10x10) with exposed pad, it is suitable for surface mounting and operates within a -40°C to 85°C temperature range. Analog supply voltage ranges from 3.13V to 3.47V, with digital supply at 1.71V to 1.89V. The AD9125BCPZRL is commonly employed in high-speed signal processing, communications infrastructure, and test and measurement equipment. It is supplied in tape and reel packaging.
Additional Information
Series: TxDAC+®RoHS Status: ROHS3 CompliantManufacturer Lead Time: 10 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 72-VFQFN Exposed Pad, CSP |
| Output Type | Current - Unbuffered |
| Mounting Type | Surface Mount |
| Number of Bits | 16 |
| Data Interface | Parallel |
| Reference Type | External, Internal |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply, Analog | 3.13V ~ 3.47V |
| Voltage - Supply, Digital | 1.71V ~ 1.89V |
| Settling Time | 20ns (Typ) |
| Supplier Device Package | 72-LFCSP-VQ (10x10) |
| Architecture | Current Source |
| Number of D/A Converters | 2 |
| INL/DNL (LSB) | ±3.7, ±2.1 |
| Differential Output | Yes |
| Programmable | Not Verified |
