AD8522AN
IC DAC 12BIT V-OUT 14DIPManufacturer: Analog Devices Inc.
Categories: Digital to Analog Converters (DAC)
Quality Control: Learn More
Analog Devices Inc. AD8522AN is a 12-bit, dual-channel digital-to-analog converter (DAC). Featuring an R-2R architecture, this component offers a voltage output that is buffered. The AD8522AN supports an SPI data interface for efficient communication. Its specifications include an INL/DNL of ±0.5 LSB, a settling time of 16µs (typical), and an internal voltage reference. The device operates over an extended temperature range of -40°C to 85°C. Supplied in a 14-PDIP package, the AD8522AN is suitable for through-hole mounting. It requires a 5V supply for both analog and digital operations. This converter is utilized in applications such as industrial automation, test and measurement equipment, and consumer electronics where precise analog signal generation is required.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 14-DIP (0.300"", 7.62mm) |
| Output Type | Voltage - Buffered |
| Mounting Type | Through Hole |
| Number of Bits | 12 |
| Data Interface | SPI |
| Reference Type | Internal |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply, Analog | 5V |
| Voltage - Supply, Digital | 5V |
| Settling Time | 16µs (Typ) |
| Supplier Device Package | 14-PDIP |
| Architecture | R-2R |
| Number of D/A Converters | 2 |
| INL/DNL (LSB) | ±0.5, ±0.5 |
| Differential Output | No |
| Programmable | Not Verified |
