AD667JP-REEL
IC DAC 12BIT V-OUT 28PLCCManufacturer: Analog Devices Inc.
Categories: Digital to Analog Converters (DAC)
Quality Control: Learn More
Analog Devices Inc. AD667JP-REEL is a 12-bit, single-channel voltage-output digital-to-analog converter. This component features an R-2R architecture and a parallel data interface. It offers a voltage output that is buffered for optimal drive capability. The INL and DNL specifications are ±0.5 LSB. The AD667JP-REEL supports both external and internal voltage references. Its settling time is rated at 4µs. This device is supplied in a 28-PLCC surface-mount package on tape and reel. Analog supply voltage ranges from ±11.4V to ±16.5V, with no specific digital supply voltage listed. This component is suitable for applications in industrial control, test and measurement, and data acquisition systems.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 28-LCC (J-Lead) |
| Output Type | Voltage - Buffered |
| Mounting Type | Surface Mount |
| Number of Bits | 12 |
| Data Interface | Parallel |
| Reference Type | External, Internal |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply, Analog | ±11.4V ~ 16.5V |
| Voltage - Supply, Digital | - |
| Settling Time | 4µs |
| Supplier Device Package | 28-PLCC (11.51x11.51) |
| Architecture | R-2R |
| Number of D/A Converters | 1 |
| INL/DNL (LSB) | ±0.5, ±0.5 |
| Differential Output | No |
| Programmable | Not Verified |
