AD5544ACPZ-1-R2
IC DAC 16BIT A-OUT 32LFCSPManufacturer: Analog Devices Inc.
Categories: Digital to Analog Converters (DAC)
Quality Control: Learn More
Analog Devices Inc. AD5544ACPZ-1-R2 is a 16-bit, quad-channel DAC featuring an R-2R architecture. This component supports a voltage supply range of 2.7V to 5.5V for both analog and digital domains. The data interface utilizes the SPI protocol for communication. The output is current-buffered with a typical settling time of 900ns. INL/DNL specifications are ±4 LSB maximum. The device is supplied in a 32-LFCSP (5x5) package, suitable for surface mounting, and is available on tape and reel. This DAC is commonly deployed in industrial automation, test and measurement equipment, and audio signal processing applications.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 32-WFQFN Exposed Pad, CSP |
| Output Type | Current - Unbuffered |
| Mounting Type | Surface Mount |
| Number of Bits | 16 |
| Data Interface | SPI |
| Reference Type | External |
| Operating Temperature | -40°C ~ 125°C |
| Voltage - Supply, Analog | 2.7V ~ 5.5V |
| Voltage - Supply, Digital | 2.7V ~ 5.5V |
| Settling Time | 900ns (Typ) |
| Supplier Device Package | 32-LFCSP (5x5) |
| Architecture | R-2R |
| Number of D/A Converters | 4 |
| INL/DNL (LSB) | ±4 (Max), ±1 (Max) |
| Differential Output | No |
| Programmable | Not Verified |
