AD5339BRMZ-REEL
IC DAC 12BIT V-OUT 8MSOPManufacturer: Analog Devices Inc.
Categories: Digital to Analog Converters (DAC)
Quality Control: Learn More
Analog Devices Inc. AD5339BRMZ-REEL is a dual, 12-bit voltage-output digital-to-analog converter. This component features an I2C serial interface for communication and offers buffered voltage output. The AD5339BRMZ-REEL exhibits excellent linearity with typical Integral Non-Linearity (INL) and Differential Non-Linearity (DNL) of ±2 LSB and ±0.2 LSB, respectively. It operates over an extended temperature range of -40°C to 105°C and supports analog and digital supply voltages from 2.5V to 5.5V. The settling time is specified at 10µs. This device is housed in an 8-MSOP package and is supplied in tape and reel. Applications for this DAC include industrial automation, medical instrumentation, and portable electronics.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-TSSOP, 8-MSOP (0.118"", 3.00mm Width) |
| Output Type | Voltage - Buffered |
| Mounting Type | Surface Mount |
| Number of Bits | 12 |
| Data Interface | I2C |
| Reference Type | External |
| Operating Temperature | -40°C ~ 105°C |
| Voltage - Supply, Analog | 2.5V ~ 5.5V |
| Voltage - Supply, Digital | 2.5V ~ 5.5V |
| Settling Time | 10µs |
| Supplier Device Package | 8-MSOP |
| Architecture | String DAC |
| Number of D/A Converters | 2 |
| INL/DNL (LSB) | ±2, ±0.2 |
| Differential Output | No |
| Programmable | Not Verified |
