ADBF518WBSWZ4XX
Digital Signal Processor, 32-Bit Size, 16-Ext Bit, 400MHz, CMOS, PQFP176Manufacturer: Analog Devices Inc.
Categories: Digital Signal Processors
Quality Control: Learn More
Analog Devices Inc. ADBF518 series digital signal processor, part number ADBF518WBSWZ4XX. This 32-bit fixed-point processor operates at a maximum clock frequency of 400MHz, utilizing CMOS technology. It features a 16-bit external data bus and a 19-bit address bus. The component is housed in a 176-terminal LFQFP package with a 0.500mm terminal pitch. Designed for surface mounting, it supports low-power operation and includes boundary scan functionality. Operating temperature ranges from -40°C to 85°C with a supply voltage between 1.164V and 1.470V. This DSP is suitable for applications in telecommunications, industrial automation, and audio processing.
Additional Information
Series: ADBF518RoHS Status: Manufacturer Lead Time: Product Status: Active-UnconfirmedPackaging: Datasheet:Download Free CAD Model:
Technical Details:
| Format | Fixed Point |
| Length | 24.0000 |
| Width | 24.0000 |
| Technology | CMOS |
| Address_Bus_Width | 19 |
| Barrel_Shifter | Yes |
| Bit_Size | 32 |
| Boundary_Scan | Yes |
| Clock_Frequency_Max | 400.0000000000000000 |
| External_Data_Bus_Width | 16 |
| Internal_Bus_Architecture | Multiple |
| JESD_30_Code | S-PQFP-G176 |
| Low_Power_Mode | Yes |
| Number_of_Terminals | 176 |
| Operating_Temperature_Max | 85.0000 |
| Operating_Temperature_Min | -40.0000 |
| Package_Body_Material | PLASTIC/EPOXY |
| Package_Code | LFQFP |
| Package_Shape | Square |
| Package_Style | FLATPACK, LOW PROFILE, FINE PITCH |
| Seated_Height_Max | 1.6000 |
| Supply_Voltage_Max | 1.4700 |
| Supply_Voltage_Min | 1.1640 |
| Supply_Voltage_Nom | 1.4000 |
| Surface_Mount | Yes |
| Terminal_Form | Gull Wing |
| Terminal_Pitch | 0.500 |
| Terminal_Position | QUAD |
| uPs_uCs_Peripheral_ICs_Type | DIGITAL SIGNAL PROCESSOR, OTHER |
