AD5260BRU200
IC POT DGTL 200K 256POS 14-TSSOPManufacturer: Analog Devices Inc.
Categories: Digital Potentiometers
Quality Control: Learn More
The Analog Devices Inc. AD5260BRU200 is a single-circuit, 256-tap digital potentiometer with a nominal resistance of 200 kOhms. This device features a logarithmic taper and operates from a single or dual supply voltage range of 4.5V to 16.5V or ±4.5V to ±5.5V, respectively. Its 14-TSSOP package facilitates surface-mount integration. The AD5260BRU200 offers a typical temperature coefficient of 35 ppm/°C and is suitable for applications in industrial automation, medical instrumentation, and consumer electronics. The memory type is volatile.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Resistance (Ohms) | 200k |
| Packaging | Tube |
| Package / Case | 14-TSSOP (0.173"", 4.40mm Width) |
| Mounting Type | Surface Mount |
| Memory Type | Volatile |
| Operating Temperature | -40°C ~ 85°C |
| Number of Taps | 256 |
| Voltage - Supply | 4.5V ~ 16.5V, ±4.5V ~ 5.5V |
| Taper | Logarithmic |
| Supplier Device Package | 14-TSSOP |
| Temperature Coefficient (Typ) | 35ppm/°C |
| Number of Circuits | 1 |
| Programmable | Not Verified |
