AD5172BRMZ50
IC DGTL POT 50KOHM 256TAP 10MSOPManufacturer: Analog Devices Inc.
Categories: Digital Potentiometers
Quality Control: Learn More
Analog Devices Inc. AD5172BRMZ50 is a dual-channel, 50k Ohm digital potentiometer featuring 256 discrete resistance steps per channel. This device utilizes an I2C serial interface for control, enabling precise adjustment of resistance ratios. Designed for surface mounting within a compact 10-MSOP package, it offers a linear taper and a wide operating temperature range of -40°C to 125°C. The AD5172BRMZ50 is suitable for applications requiring adjustable gain stages, voltage division, and filter tuning across various industrial and consumer electronics sectors. Its low wiper resistance of typically 160 Ohms and a voltage supply range of 2.7V to 5.5V contribute to its versatility in demanding designs. The device exhibits a typical temperature coefficient of 35ppm/°C with a tolerance of ±20%.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Resistance (Ohms) | 50k |
| Tolerance | ±20% |
| Features | - |
| Packaging | Tube |
| Package / Case | 10-TFSOP, 10-MSOP (0.118"", 3.00mm Width) |
| Mounting Type | Surface Mount |
| Memory Type | OTP |
| Interface | I2C |
| Configuration | Potentiometer |
| Operating Temperature | -40°C ~ 125°C |
| Number of Taps | 256 |
| Voltage - Supply | 2.7V ~ 5.5V |
| Taper | Linear |
| Supplier Device Package | 10-MSOP |
| Resistance - Wiper (Ohms) (Typ) | 160 |
| Temperature Coefficient (Typ) | 35ppm/°C |
| Number of Circuits | 2 |
| Programmable | Not Verified |
