ADUM1201WSRZ33
DGTL ISO 2500VRMS 2CH GP 8SOICManufacturer: Analog Devices Inc.
Categories: Digital Isolators
Quality Control: Learn More
Analog Devices Inc. ADUM1201WSRZ33 is a 2-channel digital isolator designed for robust data transfer in harsh environments. Operating with a supply voltage range of 3V to 5.5V, this component offers 2500Vrms of isolation, ensuring signal integrity and protection in automotive applications. Its unidirectional channel type and magnetic coupling technology facilitate reliable data transmission up to 1Mbps. Exhibiting a typical rise and fall time of 2.5ns, and a maximum pulse width distortion of 40ns, the ADUM1201WSRZ33 maintains signal fidelity. Furthermore, it boasts a high common-mode transient immunity (CMTI) of 25kV/µs, crucial for applications susceptible to electrical noise. The device is housed in an 8-SOIC package (0.154", 3.90mm width) suitable for surface mounting and operates across an industrial temperature range of -40°C to 125°C. This general-purpose isolator is commonly employed in automotive systems, industrial automation, and power supply designs.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Type | General Purpose |
| Operating Temperature | -40°C ~ 125°C |
| Voltage - Supply | 3V ~ 5.5V |
| Data Rate | 1Mbps |
| Technology | Magnetic Coupling |
| Voltage - Isolation | 2500Vrms |
| Inputs - Side 1/Side 2 | 1/1 |
| Supplier Device Package | 8-SOIC |
| Rise / Fall Time (Typ) | 2.5ns, 2.5ns |
| Common Mode Transient Immunity (Min) | 25kV/µs |
| Propagation Delay tpLH / tpHL (Max) | 150ns, 150ns |
| Isolated Power | No |
| Channel Type | Unidirectional |
| Pulse Width Distortion (Max) | 40ns |
| Grade | Automotive |
| Number of Channels | 2 |
