ADBMS6821CCSZ-RL
SINGLE ISOSPI TRANSCEIVER FOR BRManufacturer: Analog Devices Inc.
Categories: Digital Isolators
Quality Control: Learn More
SPI Digital Isolator 1 Channel 2Mbps CMTI 32-VFQFN Exposed Pad
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 10 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 32-VFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Type | SPI |
| Operating Temperature | -40°C ~ 125°C |
| Voltage - Supply | 3V ~ 5.5V |
| Data Rate | 2Mbps |
| Technology | Capacitive Coupling |
| Voltage - Isolation | - |
| Inputs - Side 1/Side 2 | 1/0 |
| Supplier Device Package | 32-QFN (5x5) |
| Rise / Fall Time (Typ) | - |
| Common Mode Transient Immunity (Min) | - |
| Propagation Delay tpLH / tpHL (Max) | - |
| Isolated Power | No |
| Channel Type | Bidirectional |
| Pulse Width Distortion (Max) | - |
| Grade | - |
| Number of Channels | 1 |
| Qualification | - |
