AD261AND-0
DGTL ISO 1.75KV GEN PURP 22DIPManufacturer: Analog Devices Inc.
Categories: Digital Isolators
Quality Control: Learn More
Analog Devices Inc. IsoLogic™ AD261AND-0 is a 5-channel general-purpose digital isolator designed for robust performance in demanding environments. This component provides 1750Vrms of isolation and features a high Common Mode Transient Immunity (CMTI) of 10kV/µs, ensuring signal integrity in the presence of rapid voltage fluctuations. Utilizing magnetic coupling technology, it offers bidirectional data transfer across its five independent channels, with 0 inputs on one side and 5 on the other. The AD261AND-0 operates from a supply voltage range of 4V to 5.75V and has a maximum propagation delay of 25ns for both low-to-high and high-to-low transitions. Packaged in a 22-DIP module for through-hole mounting, this isolator is suitable for applications in industrial automation, medical equipment, and power supply systems where reliable signal isolation is critical.
Additional Information
Series: IsoLogic™RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 22-DIP Module |
| Mounting Type | Through Hole |
| Type | General Purpose |
| Operating Temperature | -25°C ~ 85°C |
| Voltage - Supply | 4V ~ 5.75V |
| Data Rate | - |
| Technology | Magnetic Coupling |
| Voltage - Isolation | 1750Vrms |
| Inputs - Side 1/Side 2 | 0/5 |
| Supplier Device Package | 22-PDIP |
| Rise / Fall Time (Typ) | - |
| Common Mode Transient Immunity (Min) | 10kV/µs |
| Propagation Delay tpLH / tpHL (Max) | 25ns, 25ns |
| Isolated Power | No |
| Channel Type | Unidirectional |
| Pulse Width Distortion (Max) | - |
| Number of Channels | 5 |
