ADP2443ACPZN-R7
IC REG BUCK ADJ 3A 24LFCSPManufacturer: Analog Devices Inc.
Categories: DC DC Switching Regulators
Quality Control: Learn More
Analog Devices Inc. ADP2443ACPZN-R7 is a high-performance, adjustable output buck switching regulator designed for demanding applications. This component delivers up to 3A of output current and operates over an input voltage range of 4.5V to 36V, with a selectable output voltage from 0.6V up to 12V. Featuring a wide switching frequency range of 200kHz to 1.8MHz, the ADP2443ACPZN-R7 offers flexibility in component selection and power loss optimization. Its integrated synchronous rectifier enhances efficiency, making it suitable for power supplies in industrial automation, medical equipment, and telecommunications infrastructure. The device is housed in a compact 24-lead LFCSP (4x4) package with an exposed pad for improved thermal management, and is supplied on tape and reel.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 10 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 24-WFQFN Exposed Pad, CSP |
| Output Type | Adjustable |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Function | Step-Down |
| Current - Output | 3A |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Output Configuration | Positive |
| Frequency - Switching | 200kHz ~ 1.8MHz |
| Voltage - Input (Max) | 36V |
| Topology | Buck |
| Supplier Device Package | 24-LFCSP (4x4) |
| Synchronous Rectifier | Yes |
| Voltage - Output (Max) | 12V |
| Voltage - Input (Min) | 4.5V |
| Voltage - Output (Min/Fixed) | 0.6V |
