LTC1628IG-SYNC#TRPBF
IC REG CTRLR BUCK 28SSOPManufacturer: Analog Devices Inc.
Categories: DC DC Switching Controllers
Quality Control: Learn More
The Analog Devices Inc. LTC1628IG-SYNC-TRPBF is a dual-phase, synchronous buck DC-DC controller. This device features a wide input voltage range from 3.5V to 30V, enabling step-down conversion for a variety of power applications. It operates at a switching frequency of 220kHz with a maximum duty cycle of 99.4%. The controller integrates essential features such as Enable, Frequency Control, Power Good, and Soft Start for robust power management. Designed for surface mount installation in a 16-SSOP package, it facilitates efficient board space utilization. The LTC1628IG-SYNC-TRPBF is suitable for applications requiring precise and efficient voltage regulation, including industrial controls and power supplies. This component is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 10 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-SSOP (0.209"", 5.30mm Width) |
| Output Type | Transistor Driver |
| Mounting Type | Surface Mount |
| Function | Step-Down |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Output Configuration | Positive |
| Frequency - Switching | 220kHz |
| Topology | Buck |
| Voltage - Supply (Vcc/Vdd) | 3.5V ~ 30V |
| Supplier Device Package | 16-SSOP |
| Synchronous Rectifier | Yes |
| Control Features | Enable, Frequency Control, Power Good, Soft Start |
| Serial Interfaces | - |
| Output Phases | 2 |
| Duty Cycle (Max) | 99.4% |
| Clock Sync | No |
| Number of Outputs | 2 |
