LT3752MPFE-1
IC REGULATORManufacturer: Analog Devices Inc.
Categories: DC DC Switching Controllers
Quality Control: Learn More
Analog Devices Inc. LT3752MPFE-1 is a high-performance, multiphase synchronous forward controller IC designed for isolated and non-isolated switching regulators. This component features a wide input voltage range of 10.5V to 16V and a maximum duty cycle of 95%, enabling efficient power conversion. The LT3752MPFE-1 supports both step-up and step-down configurations, offering flexibility in power supply design. Its integrated synchronous rectification capability and forward converter topology contribute to high efficiency. Control features include enable, frequency control, and soft-start for optimized system startup and operation. The device operates within an extended temperature range of -55°C to 150°C, making it suitable for demanding applications. Clock synchronization is supported. The LT3752MPFE-1 is packaged in a 38-TSSOP-EP (38-TFSOP) with an exposed pad, intended for surface mounting. This controller is utilized in various industries including automotive, industrial, and telecommunications.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 38-TFSOP (0.173"", 4.40mm Width) 31 Leads, Exposed Pad |
| Output Type | Transistor Driver |
| Mounting Type | Surface Mount |
| Function | Step-Up/Step-Down |
| Operating Temperature | -55°C ~ 150°C |
| Output Configuration | Positive, Isolation Capable |
| Frequency - Switching | 100kHz ~ 500kHz |
| Topology | Forward Converter |
| Voltage - Supply (Vcc/Vdd) | 10.5V ~ 16V |
| Supplier Device Package | 38-TSSOP-EP |
| Synchronous Rectifier | Yes |
| Control Features | Enable, Frequency Control, Soft Start |
| Serial Interfaces | - |
| Output Phases | 1 |
| Duty Cycle (Max) | 95% |
| Clock Sync | Yes |
| Number of Outputs | 1 |
