LTM8025MPV#PBF
DC DC CONVERTER 0.8-24VManufacturer: Analog Devices Inc.
Categories: DC DC Converters
Quality Control: Learn More
Non-Isolated PoL Module DC DC Converter 1 Output 0.8 ~ 24V 3A 3.6V - 36V Input
Additional Information
Series: µModule®RoHS Status: ROHS3 CompliantManufacturer Lead Time: 33 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tray |
| Package / Case | 70-BLGA Module |
| Size / Dimension | 0.59"" L x 0.35"" W x 0.17"" H (15.0mm x 9.0mm x 4.3mm) |
| Mounting Type | Surface Mount |
| Type | Non-Isolated PoL Module |
| Operating Temperature | -55°C ~ 125°C |
| Applications | ITE (Commercial) |
| Voltage - Input (Max) | 36V |
| Efficiency | - |
| Current - Output (Max) | 3A |
| Supplier Device Package | 70-LGA (15x9) |
| Voltage - Input (Min) | 3.6V |
| Voltage - Output 1 | 0.8 ~ 24V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Number of Outputs | 1 |
