LTM4680IY#PBF
DC DC CNVRTR 0.5-3.3V 0.5-3.3VManufacturer: Analog Devices Inc.
Categories: DC DC Converters
Quality Control: Learn More
Analog Devices Inc. LTM4680IY-PBF is a µModule® series non-isolated Point-of-Load DC-DC converter. This component offers two regulated outputs, each adjustable from 0.5V to 3.3V, with a maximum output current of 30A per channel. The input voltage range is 4.5V to 16V, supporting high power density applications. Key features include Over-Current Protection (OCP), Over-Temperature Protection (OTP), Over-Voltage Protection (OVP), and Under-Voltage Lockout (UVLO). The LTM4680IY-PBF is housed in a 144-BGA (16x16) package, measuring 16.0mm x 16.0mm x 8.1mm, designed for efficient surface mounting. This device is well-suited for use in ITE (Commercial) applications requiring robust power delivery and thermal management.
Additional Information
Series: µModule®RoHS Status: ROHS3 CompliantManufacturer Lead Time: 39 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | OCP, OTP, OVP, UVLO |
| Packaging | Tray |
| Package / Case | 144-BBGA Module |
| Size / Dimension | 0.63"" L x 0.63"" W x 0.32"" H (16.0mm x 16.0mm x 8.1mm) |
| Mounting Type | Surface Mount |
| Type | Non-Isolated PoL Module |
| Operating Temperature | -40°C ~ 125°C |
| Applications | ITE (Commercial) |
| Voltage - Input (Max) | 16V |
| Approval Agency | - |
| Efficiency | 90% |
| Current - Output (Max) | 30A, 30A |
| Supplier Device Package | 144-BGA (16x16) |
| Voltage - Input (Min) | 4.5V |
| Voltage - Output 1 | 0.5 ~ 3.3V |
| Voltage - Output 2 | 0.5 ~ 3.3V |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Number of Outputs | 2 |
